Motor
SyncDrive Sport, 70Nm, Powered by Yamaha
Controller
RideControl Dash, full color LCD screen
Display
RideControl Dash, full color LCD screen
Battery
EnergyPak Smart 625Wh, 36V Integrated Lithium-Ion
Charger
EnergyPak 4A smart charger compact
Sizes
XS/S/M (XS: 27.5 / S-M: 29)
Colours
Metal/Black
Frame
ALUXX Aluminum, 120mm FlexPoint suspension system, 141mm Boost QR, Integrated KS18 Kickstand Mount
Fork
RockShox Recon Silver RL, 130mm travel, Lockout, 110x15mm Boost, Maxle Stealth, e-MTB optimised
Shock
RockShox Monarch RT, High Volume, 184x44mm, custom tuned
Handlebar
Giant Connect TR Riser 31.8x750~780mm (XS-S: 750 / M-L: 780)
Grips
Liv Contact Microtech Plus, Lock-on
Stem
Giant Contact
Seatpost
Giant Contact Switch, dropper, 30,9mm (XS: 75/ S:100/ M:125/ L:150)
Saddle
Liv Sylvia E+
Pedals
Aluminum Platform
Shifters
Shimano Deore,
Rear Derailleur
Shimano Deore, 12-speed
Brakes
Shimano MT420, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano MT401
Cassette
Shimano CS-M6100-12, 10-51T, 12-speed
Chain
KMC e.12 Sport, e-bike optimised
Crankset
Forged Alloy minimal Q-factor, 36T Steel Direct Mount ring (XS/S:160, M/L:165)
Bottom Bracket
-
Rims
Giant AM 27.5" / 29", Tubeless ready, 30mm inner width (XS: 27.5+ / S-M: 29)
Hubs
Shimano MT410 Boost / MT401, Center-Lock, [F] 110x15 [R] 141mm QR Micro-Spline Drive Body
Spokes
Stainless Steel
Tyres
Maxxis Rekon 29x2.4"/ 27.5x2.4" foldable, 60tpi, EXO, Tubeless Ready (XS: 27.5, S-M 29)
Extras
-
Lighting
-
Lock
-
Carrier
-
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
