2024 Liv Intrigue X Advanced E+ EL 3 E-Mountain Bike in Silver

Season:2024

Brand:LIV

Code:6029032Shoreline

Next-level performance and unforgettable fun await you on this premium e-mtb. The cutting-edge intrigue x advanced e+ elite is remarkably light yet super powerful. Get ready to feel like a pro as you shred technical terrain with confidence, accelerate up climbs, and corner at top speed.

Features:

This full-suspension e-mtb, with its short chainstay and 140mm (rear)/150mm (front) travel, is engineered to create an ultra-light, efficient and responsive ride. Exceptional shock absorption is an added bonus on rock gardens.
A potent 85nm of torque delivered by the lightweight syncdrive pro 2 mg motor is smooth and instant, keeping you efficient and in control at all times. The ultra-slim, 400wh battery hidden in the down tube minimises weight and provides a perfect balance of efficiency and range.
From the integrated control unit to the sleek console on the top tube and the internal cable routing, every design element embodies a high-end, modern look. It combines leading-edge e-mtb design with a user-friendly experience.
The range for a single battery charge can vary greatly depending on conditions such as the combined weight of the rider and cargo; wind resistance; tyre pressure and tread profile; terrain and elevation changes; road or trail surface; outdoor temperature; maintenance of the e-bike; and the condition of the battery.

Technical Information

Motor
Giant SyncDrive Pro2 85Nm, PedalPlus 6-Sensor technology
Controller
Giant RideControl Ergo3, grip integrated remote
Display
Giant RideControl GO, frame integrated LED consoleOptional wireless ANT+ display
Battery
Giant EnergyPak 400Wh, Aluminium casing with highest safety standard (EN50604), CO2 Neutral production, Giant EnergyPak Plus 200 range extender compatible
Charger
Giant EnergyPak 4A smart charger, 60% in 1:45
Connectivity
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
Sizes
XS, S, M
Colours
Gloss Shoreline / Black
Frame
Advanced-grade composite frame, Aluxx SL-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system
Fork
Marzocchi Bomber Z2 E-Tuned, 29er, 150mm travel, 44mm offset, RAIL damper Sweep-Adj, Kabolt 110
Shock
Fox Float Performance, EVOL Large Volume sleeve, 2pos, 185x52.5mm Trunnion mount, custom tuned
Handlebar
Giant Contact 35 Trail
Grips
Liv Tactal Pro-E Single Lock-On Grips
Stem
Giant Contact SL 35
Seatpost
Tranz-X Rad+ dropper, 30.9mm, 30mm travel adjustable (XS/S:90-125mm, M:120-150mm)
Saddle
Liv Sylvia E+
Pedals
PEDALS NOT SUPPLIED
Shifters
Shimano Deore 1x12
Front Derailleur
MRP HD2 co-moulded chain guide
Rear Derailleur
Shimano Deore
Brakes
Shimano BR-MT420, 4-piston, hydraulic disc, 203mm
Brake Levers
Shimano Deore, I-spec EV
Cassette
Shimano CS-M6100-12, 10-51T
Chain
KMC e.12 Turbo, EcoProteq, e-bike optimised
Crankset
Praxis N.W. 36T Cold Forged 4130 premium steel Praxis e-Cranks
Bottom Bracket
n/a
Rims
AM30, Tubeless ready, 30mm inner width, 29" [F] / 27.5" [R]
Hubs
Shimano MT410 Boost, Center-Lock, 110x15 [F] 148x12 Shimano Micro-Spline Drive Body Thru-axle [R]
Spokes
Sapim E-Lite [R] Race [F], e-bike optimised
Tyres
Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO [F]Maxxis Dissector 27.5x2.4" Foldable, TLR, EXO [R]
Extras
Tubeless kit (liquid, valves, levers, manual, tool) Inner tube supplied
Lighting
Optional:- Giant Recon series e-bike lights available and direct connectable

Sizing Information

Size	Height
XS	152 - 163cm
S	158 - 169cm
M	164 - 175cm

bike diagram with measurements referenced in table that follows

		XS	S	M
		LOW\|HIGH	LOW\|HIGH	LOW\|HIGH
A	SEAT TUBE LENGTH(mm)	380	400	425
A1	SEAT POST INSERTION DEPTH(mm)	199	219	244
B	SEAT TUBE ANGLE	77.2°	77.2°	76.0°
C	TOP TUBE LENGTH(mm)	557\|555	572\|570	597\|595
D	HEAD TUBE LENGTH(mm)	95	95	100
E	HEAD TUBE ANGLE	65.7°\|66.5°	65.7°\|66.5°	65.8°\|66.5°
F	FORK RAKE(mm)	44	44	44
G	TRAIL(mm)	113.1\|108	113.1\|108	113.1\|108
H	WHEELBASE(mm)	1174\|1175	1188\|1190	1200\|1201
I	CHAIN STAY LENGTH(mm)	447\|447	447\|447	447\|447
J	BOTTOM BRACKET DROP(mm)	30\|20	30\|20	30\|20
K	STACK(mm)	606\|601	606\|601	611\|605
L	REACH(mm)	419\|427	434\|442	444\|452
M	STAND OVER HEIGHT(mm)	722\|730	726\|735	717\|726
N	HANDLEBAR WIDTH(mm)	760	760	800
O	STEM LENGTH(mm)	40	40	40
P	CRANK LENGTH(mm)	160	160	165
Q	WHEEL SIZE	[F] 29" [R	[F] 29" [R	[F] 29" [R
