Giant Reign E+ 2 MX Pro eMountain Bike in Black Diamond/Black

Season:2022

Brand:Giant

Code:2113337BLKDiamondBLK

Tested and developed by Giant's eBike Enduro pros, this updated trail ripper gives you the power to enjoy the best parts of the ride again and again.

A 29-inch front wheel and 27.5-inch rear wheel work together to offer superior handling and agility on technical terrain. The updated frameset features new geometry with a shorter rear end and longer reach. New control units include RideControl Go, which is integrated into the top tube, and RideControl Ergo 3, attached to the handlebar near the grip. A new flip chip feature lets you adjust frame geometry for riding style and terrain.

Features:

Trail technology - Proven Maestro rear suspension (160mm) and a powerful but compact SyncDrive Pro motor technology boost your capabilities on steep climbs and rugged descents.
Total control - RideControl Ergo 3 offers integrated, user-friendly button controls that are easy to use. The Giant E-bike App gives you tuning options and E-bike specific fitness tracking.
Long-lasting power - Climb steep mountains and enjoy fun descents all day long with the downtube-integrated EnergyPak

Technical Information

Motor
SyncDrive Pro, 85Nm, powered by Yamaha
Controller
RideControl Ergo 3, grip integrated
Display
RideControl GO, frame integrated LED displayANT+ Wireless display compatible
Battery
EnergyPak Smart 625WhEnergyPak Plus range extender compatible
Charger
EnergyPak 6A smart charger
Sizes
S, M, L, XL
Colours
Black Diamond
Frame
ALUXX SL-grade Aluminum, Advanced Forged Composite Upper Rocker, 160mm Maestro suspension system, 'Boost' 148x12mm, UDHTM derrailleur hanger
Fork
RockShox ZEB Select 29er, 170mm travel, Charger RC damper, 15x110 Boost, Maxle Stealth
Shock
Fox Float DPX2 Performance, EVOL Large Volume sleeve, 2-position lever, 205x62.5mm Trunnion mount, custom tuned
Handlebar
Giant Contact Trail, 35x800mm
Grips
Giant Tactal Pro-E, single lock-on
Stem
Giant Contact SL 35
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125, M: 150, L/XL:170)
Saddle
Giant Romero Trail
Pedals
Flat pedal
Shifters
SRAM NX
Front Derailleur
MRP 1X HD2 custom co-molded chain guide
Rear Derailleur
SRAM GX 12-speed
Brakes
SRAM Code R, hydraulic disc, 220mm[F] /200mm[R]
Brake Levers
SRAM Code R
Cassette
SRAM PG-1230, 11-50T, 12-speed
Chain
SRAM NX Eagle PowerLock
Crankset
SRAM X-Sync Eagle 36T chainring Praxis e-Cadet+ custom forged crankarm set (S/M:160, L/XL:165)
Bottom Bracket
-
Rims
Giant AM 29"[F] 27.5"[R], Tubeless ready, 30mm inner width
Hubs
Giant eTracker Boost, Sealed cartridge bearing, 6-bolt, , [F] 110x15 [R] 148x12mm Thru-axle
Spokes
Sapim E-Lite [r] Race [f]
Tyres
Maxxis Minion DHF 29x2.6" foldable, Tubeless, EXO+, 3C MaxxTerra[F]Maxxis High Roller II 27.5x2.5" foldable, Tubeless, DoubleDown, 3C MaxxTerra Compound [R]
Extras
Tubeless kit (liquid, valves, levers, manual, tool)
Lighting
Optional:- Giant Recon series e-bike lights available and direct connectable
Lock
Torx 25 Battery Lock with built-in Torque limiter
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

Sizing Information

bike diagram with measurements referenced in table that follows

		S	M	L	XL
		LOW\|HIGH	LOW\|HIGH	LOW\|HIGH	LOW\|HIGH
A	SEAT TUBE LENGTH(mm)	400	425	450	475
B	SEAT TUBE ANGLE	76.7°\|77.5°	76.7°\|77.5°	76.7°\|77.5°	76.7°\|77.5°
C	TOP TUBE LENGTH(mm)	569\|568	595\|594	622\|621	649\|648
D	HEAD TUBE LENGTH(mm)	100	100	110	120
E	HEAD TUBE ANGLE	63.7°\|64.5°	63.7°\|64.5°	63.7°\|64.5°	63.7°\|64.5°
F	FORK RAKE(mm)	44	44	44	44
G	TRAIL(mm)	135.5\|132.1	135\|132	135\|132	135.5\|132.1
H	WHEELBASE(mm)	1209\|1210	1236\|1237	1265\|1266	1295\|1296
I	CHAIN STAY LENGTH(mm)	454\|454	454\|454	454\|454	454\|454
J	BOTTOM BRACKET DROP(mm)	25\|15	25\|15	25\|15	25\|15
K	STACK(mm)	636\|632	635\|632	645\|641	654\|650
L	REACH(mm)	425\|430	450\|455	475\|480	500\|505
M	STAND OVER HEIGHT(mm)	785\|789	772\|776	771\|775	768\|772
N	HANDLEBAR WIDTH(mm)	800	800	800	800
O	STEM LENGTH(mm)	40	40	50	50
P	CRANK LENGTH(mm)	160	160	165	165
Q	WHEEL SIZE	F29" / R27.5"	F29" / R27.5"	F29" / R27.5"	F29" / R27.5"
